UPM3 SOLAR
UPM3 SOLAR is an OEM high efficiency circulator offering flexible solutions for thermal solar systems – no matter if matched flow, constant flow or drainback. It is applicable for solar fluid up to 130° C and designed to work with or without PWM signal, allowing you to upgrade your systems without having to change the controller.
| LIQUID: |
| Pumped liquid: |
|
Water |
| Liquid temperature range: |
|
2 .. 110 °C |
| Selected liquid temperature: |
|
60 °C |
| Density: |
|
983.2 kg/m³ |
| |
| TECHNICAL: |
| TF class: |
|
110 |
| Approvals: |
|
CE,VDE |
| |
| MATERIALS: |
| Pump housing: |
|
Cast iron |
| Impeller: |
|
PES 30% GF |
| |
| INSTALLATION: |
| t max amb: |
|
70 °C |
| Maximum operating pressure: |
|
10 bar |
| Port-to-port length: |
|
130 mm |
| |
| ELECTRICAL DATA: |
| Power input - P1: |
|
2 .. 45 W |
| Mains frequency: |
|
50 Hz |
| Rated voltage: |
|
1 x 230 V |
| Maximum current consumption: |
|
0.04 .. 0.48 A |
| Enclosure class (IEC 34-5): |
|
X4D |
| |
| OTHERS: |
| Energy (EEI): |
|
0.20 |
| Net weight: |
|
1.76 kg |
| Gross weight: |
|
2.12 kg |
